Item |
Descriptions |
| General |
Principle |
Colorimetric |
| Method |
End point, Fixed time, Kinetic, Absorbance, Factor |
| Parameters |
Can program more than 200 parameters |
| Mode |
Quatz flowcell,disposable cuvette |
| Optical system |
Photometer |
Filter |
| Lamp |
halogen lamp, 6V 10W, 2000 hours |
| Wavelenghts |
YSTE-21B: 340、380、405、505、546、578、620nm |
| Wavelenght accuracy |
±2nm |
| Stray light |
≤0.5% |
| Absorbance repeatility |
≤ 1% |
| Half-wave width |
≤12nm |
| Reaction system |
Measure volume |
32 ul |
| Heating system |
Element |
Peltier |
| Temperature |
RT,30,37±0.3 ℃ |
| Specification |
Storage |
15,000 results |
| Input |
YSTE-21B: 5 inch touch screen & keypad |
| Output |
Internal printer |
| Interface |
RS 232 |
| Printer paper |
80×35mm |
| Dimension |
355mm×330mm×175mm |
| Software |
LIS |
Support LIS |
| Print |
Auto print, manual print |
| Language |
English, Portuguese, French, Spanish |
| Others |
Power requirement |
100~240 AC, 50/60Hz |
| Power |
≤180VA |
| Work temperature |
10-30°C |
| Relative humidity |
≤ 85% |
| Atmospheric pressure |
86.0kPa-106.0kPa |
| Net weight |
5.6 KG |
| Performance |
Carry over |
≤1% |
| Precision |
ALT≤5%;TP≤2.5%;UREA≤3.5% |
