| Model | YSTE-LC3100I | YSTE-LC3100GH | YSTE-LC3100QL | |
| High Pressure Constant Flow Pump | Quantity | 1 Set | 2 Set | 1 Set |
| Flow Rate Range | 0.001mL/min-10.000mL/min | |||
| Flow Accuracy | ≤±0.2% (1.00ml/min, H2O,R.T.,8.5MPa) | |||
| Flow Precision | RSD≤0.075% (1.00ml/min, H2O,R.T.,8.5MPa) | |||
| Maximum Pressure | 45MPa | |||
| Pressure accuracy | ≤±3.0% | |||
| Pressure pulsation | ≤0.1MPa | |||
| UV/VIS Detector |
Wavelength Range | 190-700nm | ||
| Wavelength Repeatability | ≤0.1nm | |||
| Wavelength Accuracy | ≤±1.0nm | |||
| Band Width | 8nm | |||
| Response Time | 0.0s-5s | |||
| Baseline Noise | ≤±0.5×10-5AU | |||
| Drift | ≤1.0×10-4AU/h | |||
| Path length | 10 mm(analytical cell) | |||
| Light Source | Deuterium Lamp | |||
| Low-Pressure Gradient Unit | Integrated vacuum degasser | / | / | 4 channel |
| Composition Rang | 0-100% | |||
| Composition Precision | ≤0.2% RSD | |||
| Composition Accuracy | ≤±2.0% | |||
| Data-processing Workstation | Internal and external standard calculation methods Automatically displays, prints, exports and starts other programs after the completion of a measurement. Comply with the requirements of the 21 CFR Part 11 directive of the FDA |
|||
| 3100 System Kits | 1 Set | |||
| Power Supply | AC110/220V±10%, 50/60Hz | |||
| Optional Accessory | Column Oven, Autosampler, Degasser, Diode Array Detector, Refractive Index Detector, Evaporative Light Scattering Detector, Fluorescence Detector | |||
| Package Size(W*D*H) | 600*440*380mm*4 | |||
| Gross Weight | 68kg |
|||
